EllisDon, in partnership with Walters Steel, has begun installation of the King Arches, the supporting structure for the Freedom Mobile Arch’s iconic canopy. Pre-assembled and spliced on a custom truss rack, the installation went smoothly and without a hitch.
The Freedom Mobile Arch is a new open-air outdoor entertainment venue located on the grounds of the Pacific National Exhibition’s (PNE) Playland amusement park. It will provide a much-needed mixed-use venue space for concerts, community events, esports events and more. Projected to seat 10,000, the amphitheatre also boasts a canopy that when completed, will have the largest clear span in the world.
“The canopy is incredibly challenging, and the installation is going to be equally as rewarding,” said Brendon Vining, Senior Project Manager, EllisDon. “Watching the first structures rise to support the canopy is truly exciting and no small task. It’s been an outstanding example of collaboration and teamwork between EllisDon, EllisDon Forming, and Walters Steel.”

This installation is the first key milestone in the construction of the canopy roof:

• The first of 27 pieces, was 20m long, and weighed 16,000kg;
• It was pre-assembled and spliced on a custom truss rack for installation;
• The arches will connect to three concrete buttresses, the building of which is the self-performed work of EllisDon Forming;
• Upon completion, the King Arches will support the mass timber beams that form the canopy.

As the first step toward the completion of the canopy, this achievement highlights the power of innovation and engineering excellence, showcasing EllisDon’s expertise in delivering iconic projects.
Once finished, this striking canopy will not only become a recognizable landmark but also serve as a vibrant hub for arts and culture at the Pacific National Exhibition (PNE).
We are truly grateful for the teamwork exhibited between all partners involved, to exhibit precision and efficiency in ensuring a seamless installation.
